Phylotree.js(绘制进化树)

使用phylotree.js绘制进化树

JavaScript

Tip

nwk示例文件: AT2G01080_mafft.nwk

((((Ghi_A01G00036:0.00053,Ghi_D01G00036:0.01923)0.995:0.09853,(Ghi_A03G13296:0.01822,Ghi_D02G12776:0.00318):0.04347)0.894:0.08498,(Ghi_A05G09376:0.11190,Ghi_D05G04441:0.03452)1.000:1.44064)0.610:0.06912,AT2G01080:0.06912);

<link rel="stylesheet" type="text/css" href="http://yanglab.hzau.edu.cn/static/resource_js/exp/phylotree.css">
<link rel="stylesheet" type="text/css" href="http://yanglab.hzau.edu.cn/static/css/bootstrap.min.css">
<script type="text/javascript" charset="utf8" src="http://code.jquery.com/jquery-1.10.2.min.js"></script>
<script type="text/javascript" charset="utf8" src="http://yanglab.hzau.edu.cn/static/resource_js/exp/d3.v3.min.js"></script>
<script type="text/javascript" charset="utf8" src="http://yanglab.hzau.edu.cn/static/js/underscore-min.js"></script>
<script type="text/javascript" charset="utf8" src="http://yanglab.hzau.edu.cn/static/resource_js/exp/phylotree.js"></script>

<div>
  <svg id="tree_display" style="width:320px"></svg>
</div>

<script>
  $(document).ready(function() {
    var file_name = './AT2G01080_mafft.nwk'; //加载nwk进化树文件，自行修改文件路径
    d3.text(file_name, function(error, newick) {
      var height = 550,
        width = 290,
        tree = d3.layout.phylotree()
          .svg(d3.select("#tree_display"))
          .options({
            'left-right-spacing': 'fit-to-step',
            'top-bottom-spacing': 'fit-to-size',
            'selectable': true,
            'reroot': false,
            'hide': false,
            'show-scale': false
          })
          .align_tips(true)
          .font_size(14)
          .size([height, width])
          .node_circle_size(0);
      tree(newick).layout();
      function my_node_style_text(node) {
        node['text-italic'] = !node['text-italic'];
        d3.layout.phylotree.trigger_refresh(tree);
      }
      function my_menu_title(node) {
        if (node['text-italic']) {
          return "Remove Italics";
        }
        return "Custom function";
      }
      tree.get_nodes()
        .filter(d3.layout.phylotree.is_leafnode)
        .forEach(function(tree_node) {
          d3.layout.phylotree.add_custom_menu(tree_node, // add to this node
            my_menu_title, // display this text for the menu
            function() { //Custom function
              console.log(tree_node['name'])
            },
            d3.layout.phylotree.is_leafnode
          );
        });
    })
  })
</script>

Vue

Tip

以下示例中, underscore-vue-min.js、phylotree-vue.js存放在public/js中, phylotree.css存放在public/css中, nwk文件放在public文件夹中。
其中, underscore.js文件使用http://yanglab.hzau.edu.cn/static/js/underscore-vue-min.js。
其中, phylotree.js文件使用http://yanglab.hzau.edu.cn/static/js/phylotree-vue.js。

<template>
  <div>
    <svg id="tree_display" style="width:300px;"></svg>
  </div>
</template>

<script>
/* eslint-disable */
import { phylotree } from '@/../public/js/phylotree-vue.js'
export default {
  name: 'tree',
  components: {},
  data() {
    return {}
  },
  mounted() {
    this.$nextTick(function() {
      this.draw()
    })
  },
  methods: {
    draw() {
      var file_name = './AT2G01080_mafft.nwk'
      var that = this
      d3.text(file_name, function(error, newick) {
        if (error) {
          that.error_show = true
          return
        } else {
          that.error_show = false
        }
        var height = 500,
          width = 290,
          tree = d3.layout
            .phylotree()
            .svg(d3.select('#tree_display'))
            .options({
              'left-right-spacing': 'fit-to-step',
              'top-bottom-spacing': 'fit-to-size',
              selectable: true,
              reroot: false,
              hide: false,
              'show-scale': false
            })
            .align_tips(true)
            .font_size(14)
            .size([height, width])
            .node_circle_size(0)
        tree(newick).layout()
        function my_menu_title(node) {
          if (node['text-italic']) {
            return 'Remove Italics'
          }
          return 'console.log  ' + node['name']
        }
        tree
          .get_nodes()
          .filter(d3.layout.phylotree.is_leafnode)
          .forEach(function(tree_node) {
            d3.layout.phylotree.add_custom_menu(
              tree_node, // add to this node
              my_menu_title, // display this text for the menu
              function() {
                console.log(tree_node['name'])
              },
              d3.layout.phylotree.is_leafnode
            )
          })
        var tree_arr = tree.get_nodes()
        var genes = []
        tree_arr.forEach(function(eachnode) {
          if (tree.is_leafnode(eachnode)) {
            genes.push(eachnode.name)
          }
        })
        that.genes = genes.join(',')
      })
    }
  }
}
</script>

<style scoped>
/* 使用进化树页面到css文件的相对路径, 需自行调整 */
@import '../../../public/css/phylotree.cs';
</style>
